PFC function HLG-320H-C1050 Constant current outdoor 1050mA 320w led driver

HLG Series LED Driver Features:

1. Bulit-in active PFC function
2. Function options: output adjustable via potentiometer; 3 in 1 dimming
3.Constant voltage + Constant current mode output
4. IP67 / IP65 for indoor outdoor installations
5. 7 years warranty
6. Metal housing with class I design
7. Typical lifetime > 62000 hours

HLG series led driver  is high-grade waterproof led driver models, IP67/IP65 design for metal power case. HLG-C with complete protections and safety certificates. HLG-C switching power supply has long life, high reliability and high efficiency, 7 years warranty. HLG-C led driver compliance to worldwide safety regulations for lighting, suitable for dry/ damp/ wet location. This Led driver combined with connectors provide a pleasing and imposing aesthetic with a unique and function design that combines modern aesthetics with the power of a high- grade product. Differencing from other AC/DC led driver, HLG-C series led driver with constant current design.
Meanwell is a leading standard led driver manufacturers in the world. KULON electronics is the biggest agent of “MeanWell Power Supply” brand in the china. We do not only provide you products, we also offer you solutions. “To be your green and energy saving power solution expert” is our goal.

LED Driver Parameter

MODEL		HLG-320H-C700	HLG-320H-C1050	HLG-185H-C1400	HLG-185H-C1750
OUTPUT	RATED CURRENT	700mA	1050mA	1400mA	1750mA
	CONSTANT CURRENT REGION	214 ~ 428V	152 ~ 305V	114V ~ 229V	91V ~ 183V
	Rated POWER	299.6W	320.25W	320.6W	320.25W
	OPEN CIRCUIT VOLTAGE (max.)	435V	311V	234V	187V
	CURRENT ADJ. RANGE	Can be adjusted by internalpotentiometer (A type only)
		350 ~ 700mA	525 ~ 1050mA	700 ~ 1400mA	875 ~ 1750mA
	CURRENT TOLERANCE	±5%
	SET UP TIME	1000ms/115VAC 500ms/230VAC

MODEL		HLG-320H-C700	HLG-320H-C1050	HLG-185H-C1400	HLG-185H-C1750
INPUT	VOLTAGERANGE	90 ~ 305VAC 127 ~ 431VDC
	FREQUENCYRANGE	47 ~ 63Hz
	EFFICIENCY	94%	94%	94%	94%
	AC CURRENT	3.5A / 115VAC           1.65A / 230VAC    1.45A / 277VAC
	INRUSH CURRENT	COLD START 70A/230VAC
	LEAKAGECURRENT	<0.75mA / 277VAC

MODEL		HLG-320H-C700	HLG-320H-C1050	HLG-320H-C1400	HLG-320H-C1750
PROTECTION	OVERVOLTAGE	436 ~ 460V	320 ~ 352V	235 ~ 252V	192 ~ 211V
		Shut down and latch off o/p voltage, re-power on to recover
	SHORT CIRCUIT	Constant current limiting, recovers automatically after fault condition is removed
	OVER TEMPERATURE	Shut down o/p voltage, recovers automatically after temperature goes down
OTHERS	Packing	1.88Kg; 8pcs/16Kg/0.92CUFT
	Dimention	252*90*43.8mm (L*W*H)
NOTE	1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature. 2. Ripple & noise are measured at 20MHz of bandwidth by using a 12 twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor. 3. Tolerance : includes set up tolerance, line regulation and load regulation  4. Line regulation is measured from low line to high line at rated load.   5. Load regulation is measured from 0% to 100% rated load. 6. The Led driver is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that it still meets EMC directives
